CO

71mm

System Features

Traditional aluminum system for sliding openings.

Aluminum Profiles
• Aluminum profiles are extruded in aluminum alloy 6060 for architecture according to standard NP EN 12020-02;
• Average thickness of aluminum profiles is 1.3mm.

Fixed Frames
• Section of the fixed frame with 2 tracks of 70.5mm for straight cut installation;
• Section of the fixed frame with 3 tracks of 106.5mm for straight cut installation.

Movable Frames
• Section of the movable frames of 27.8mm for straight cut installation;
• Filling from 4mm to 18mm.

Dimensions and Handling
• Maximum weight of 80 kg per sash;
• Opening possibilities: 2, 3, 4 sashes and tri-rail, movable and/or fixed.
