APi System
Opening system with RPM - 85 mm

System features

Opening system with thermal break and high thermal and acoustic performances.

APi system allows 3 frames versions:
• Straight line;
• Curved line;
• Oval line.

APi system allows the application of double or triple high performance glass to meet the requirements of thermal and acoustic insulation.

With optimum thermal insulation and with the application of an innovative product called baguette ThermoProfile, APi System provides high comfort and high energy savings performances.

Aluminium profiles
• The aluminium profiles are extruded in 6060 architecture aluminium alloy according to NP EN 12020-02 norm.
• Thermal break is obtained by insertion of 39 mm insulated polyamide omega rods reinforced with 25% fibre glass.
• Aluminium profiles with average thickness of 1.7 mm.

Fixed rims
• 85 mm fixed frame section with triple chamber;
• Profiles with thermal break with sticks of 39 mm ómega type polyamide;
• Fixed rims with double quick grip square and alignment brackets for mitre mounting;
• Sleepers with dual union for more effective grip;
• Traditional fixed rims for the domestic market;
• Fixed hoop with exterior and interior clip for 30, 50 or 80 mm shells.

Mobile rims
• 93 mm triple chamber frame section;
• Profiles with thermal break with sticks of 39 mm ómega type polyamide;
• Mobile rims with double quick grip square and alignment brackets for mitre mounting;
• Inverter profile with lug for better implementation of the top inverter.

Sizing and maneuverability
• Minimum - maximum sheet dimensions: 457 mm - 1700 mm (L); 457 mm - 3000 mm (H);
• Maximum weight for windows or balcony doors with inward-stop up to 170 Kg;
• Maximum weight for entry doors up to 160 Kg/leaf;
• Opening possibilities: fixed, internal fitting 1 or 2 sheets with or without inward-stop, external fitting, hinged, projecting, harmonium and inward-parallel;
• Profile solution for pedestrian or balcony with interior or exterior openning doors, according to PMR standard (persons with reduced mobility);
• Filling for double or triple glass from 20 mm to 70 mm;
• Tightness ensured by EPDM double joints (interior and central), with insulated bi-material central joint.

Performances
• System certified by Initial type laboratorial test (ITT) according to EN 14351-1 product standard for the purposes of CE marking.


Categories achieved in the evaluation of APi system window tipology:
• Air permeability: Class 4 (EN 1026 testing standard)
• Water tightness: Class E1500 (EN 1027 testing standard)
• Wind resistance: Class C5 (EN 12211 standard test)

Categories achieved in the evaluation of APi system balcony door tipology:
• Air permeability: Class 4 (EN 1026 testing standard)
• Water tightness: Class 9A (EN 1027 testing standard)
• Wind resistance: Class C4 (EN 12211 standard test)

Categories achieved in the evaluation of APi system doorway tipology:
• Air permeability: Class 4 (EN 1026 testing standard)
• Water tightness: Class E1050 (EN 1027 testing standard)
• Wind resistance: Class C4 (EN 12211 standard test)

Heat transfer coefficient of 2 sheets leaf with 1.20 m x 1.50 m with glass Ug = 0.5 W / m2K with "Warm Edge" interim effect:
• Uw = 1.09 W/m2K

Acoustic attenuation coefficient of 2 sheets leaf:
• Rw (C ; Ctr) = 41 dB (-2, -5)

Areas of application according to RCCTE (depending on the Ug value): I1, I2, I3, V1, V2, V3
